063G2030 Danfoss Pressure transmitter, MEP 2250

063G2030 Danfoss Pressure transmitter, MEP 2250

Original price was: $504.69.Current price is: $100.94.

SKU: 063G2030 Category: Tag:

Description

Product details

Gross weight 0.06 kg
Net weight 0.06 kg
EAN 5702428908900
Gross weight 0.06 kg
Net weight 0.06 kg
EAN 5702428908900



+ output Pin 4
+ supply Pin 2
– common Pin 1
Accuracy, typical +/- FS [%] 0.5 %
Ambient temperature range [°C] [Max] 125 °C
Ambient temperature range [°C] [Min] -40 °C
Ambient temperature range [°F] [Max] 257 °F
Ambient temperature range [°F] [Min] -40 °F
Burst pressure [bar] 640 bar
Burst pressure [psig] 9280 psig
Compensated temp. range [°C] [Max] 125 °C
Compensated temp. range [°C] [Min] -40 °C
Compensated temp. range [°F] [Max] 257 °F
Compensated temp. range [°F] [Min] -40 °F
Electrical conn. comments Au coated
Electrical conn. Male/Female Male
Electrical connection Deutsch
Electrical connection size 4 pin
Enclosure rating IP IP67
Identical product 063G5030
Medium temperature range [°C] [Max] 125 °C
Medium temperature range [°C] [Min] -40 °C
Medium temperature range [°F] [Max] 257 °F
Medium temperature range [°F] [Min] -40 °F
Output signal Voltage
Output signal [V] [Max] 4.5 V
Output signal [V] [Min] 0.5 V
Overload pressure max. [bar] 48 bar
Overload pressure max. [psig] 696 psig
Packing format Multi pack
Pressure connection HEX [mm] 22 mm
Pressure connection size 7/16-20
Pressure connection standard SAE J1926/2
Pressure connection type UNF
Pressure Male/Female Male
Pressure range [bar] [Max] 20 bar
Pressure range [bar] [Min] 0 bar
Pressure range [psi] [Max] 290 psi
Pressure range [psi] [Min] 0 psi
Pressure unit reference Gauge (relative)
Product group Sensors
Product name Pressure transmitter
Pulse-snubber Yes
Quantity per packing format 48 pc
Response time max. [ms] 1 ms
Specification key MEP 2250-23-3-010-C10-C3BD08
Supply voltage [V] DC [Max] 30 V
Supply voltage [V] DC [Min] 8 V
Type MEP 2250
+ output Pin 4
+ supply Pin 2
– common Pin 1
Accuracy, typical +/- FS [%] 0.5 %
Ambient temperature range [°C] [Max] 125 °C
Ambient temperature range [°C] [Min] -40 °C
Ambient temperature range [°F] [Max] 257 °F
Ambient temperature range [°F] [Min] -40 °F
Burst pressure [bar] 640 bar
Burst pressure [psig] 9280 psig
Compensated temp. range [°C] [Max] 125 °C
Compensated temp. range [°C] [Min] -40 °C
Compensated temp. range [°F] [Max] 257 °F
Compensated temp. range [°F] [Min] -40 °F
Electrical conn. comments Au coated
Electrical conn. Male/Female Male
Electrical connection Deutsch
Electrical connection size 4 pin
Enclosure rating IP IP67
Identical product 063G5030
Medium temperature range [°C] [Max] 125 °C
Medium temperature range [°C] [Min] -40 °C
Medium temperature range [°F] [Max] 257 °F
Medium temperature range [°F] [Min] -40 °F
Output signal Voltage
Output signal [V] [Max] 4.5 V
Output signal [V] [Min] 0.5 V
Overload pressure max. [bar] 48 bar
Overload pressure max. [psig] 696 psig
Packing format Multi pack
Pressure connection HEX [mm] 22 mm
Pressure connection size 7/16-20
Pressure connection standard SAE J1926/2
Pressure connection type UNF
Pressure Male/Female Male
Pressure range [bar] [Max] 20 bar
Pressure range [bar] [Min] 0 bar
Pressure range [psi] [Max] 290 psi
Pressure range [psi] [Min] 0 psi
Pressure unit reference Gauge (relative)
Product group Sensors
Product name Pressure transmitter
Pulse-snubber Yes
Quantity per packing format 48 pc
Response time max. [ms] 1 ms
Specification key MEP 2250-23-3-010-C10-C3BD08
Supply voltage [V] DC [Max] 30 V
Supply voltage [V] DC [Min] 8 V
Type MEP 2250

Product name: Pressure transmitter, Type: MEP 2250, Pressure range [psi]: 0.00 – 290.00, Pressure range [bar]: 0.00 – 20.00, Pressure connection size: 7/16-20, Pressure connection type: UNF, Output signal [V]: 0.5000 – 4.5000, Electrical connection size: 4 pin, Electrical connection: Deutsch

Product details

Gross weight 0.06 kg
Net weight 0.06 kg
EAN 5702428908900
Gross weight 0.06 kg
Net weight 0.06 kg
EAN 5702428908900



+ output Pin 4
+ supply Pin 2
– common Pin 1
Accuracy, typical +/- FS [%] 0.5 %
Ambient temperature range [°C] [Max] 125 °C
Ambient temperature range [°C] [Min] -40 °C
Ambient temperature range [°F] [Max] 257 °F
Ambient temperature range [°F] [Min] -40 °F
Burst pressure [bar] 640 bar
Burst pressure [psig] 9280 psig
Compensated temp. range [°C] [Max] 125 °C
Compensated temp. range [°C] [Min] -40 °C
Compensated temp. range [°F] [Max] 257 °F
Compensated temp. range [°F] [Min] -40 °F
Electrical conn. comments Au coated
Electrical conn. Male/Female Male
Electrical connection Deutsch
Electrical connection size 4 pin
Enclosure rating IP IP67
Identical product 063G5030
Medium temperature range [°C] [Max] 125 °C
Medium temperature range [°C] [Min] -40 °C
Medium temperature range [°F] [Max] 257 °F
Medium temperature range [°F] [Min] -40 °F
Output signal Voltage
Output signal [V] [Max] 4.5 V
Output signal [V] [Min] 0.5 V
Overload pressure max. [bar] 48 bar
Overload pressure max. [psig] 696 psig
Packing format Multi pack
Pressure connection HEX [mm] 22 mm
Pressure connection size 7/16-20
Pressure connection standard SAE J1926/2
Pressure connection type UNF
Pressure Male/Female Male
Pressure range [bar] [Max] 20 bar
Pressure range [bar] [Min] 0 bar
Pressure range [psi] [Max] 290 psi
Pressure range [psi] [Min] 0 psi
Pressure unit reference Gauge (relative)
Product group Sensors
Product name Pressure transmitter
Pulse-snubber Yes
Quantity per packing format 48 pc
Response time max. [ms] 1 ms
Specification key MEP 2250-23-3-010-C10-C3BD08
Supply voltage [V] DC [Max] 30 V
Supply voltage [V] DC [Min] 8 V
Type MEP 2250
+ output Pin 4
+ supply Pin 2
– common Pin 1
Accuracy, typical +/- FS [%] 0.5 %
Ambient temperature range [°C] [Max] 125 °C
Ambient temperature range [°C] [Min] -40 °C
Ambient temperature range [°F] [Max] 257 °F
Ambient temperature range [°F] [Min] -40 °F
Burst pressure [bar] 640 bar
Burst pressure [psig] 9280 psig
Compensated temp. range [°C] [Max] 125 °C
Compensated temp. range [°C] [Min] -40 °C
Compensated temp. range [°F] [Max] 257 °F
Compensated temp. range [°F] [Min] -40 °F
Electrical conn. comments Au coated
Electrical conn. Male/Female Male
Electrical connection Deutsch
Electrical connection size 4 pin
Enclosure rating IP IP67
Identical product 063G5030
Medium temperature range [°C] [Max] 125 °C
Medium temperature range [°C] [Min] -40 °C
Medium temperature range [°F] [Max] 257 °F
Medium temperature range [°F] [Min] -40 °F
Output signal Voltage
Output signal [V] [Max] 4.5 V
Output signal [V] [Min] 0.5 V
Overload pressure max. [bar] 48 bar
Overload pressure max. [psig] 696 psig
Packing format Multi pack
Pressure connection HEX [mm] 22 mm
Pressure connection size 7/16-20
Pressure connection standard SAE J1926/2
Pressure connection type UNF
Pressure Male/Female Male
Pressure range [bar] [Max] 20 bar
Pressure range [bar] [Min] 0 bar
Pressure range [psi] [Max] 290 psi
Pressure range [psi] [Min] 0 psi
Pressure unit reference Gauge (relative)
Product group Sensors
Product name Pressure transmitter
Pulse-snubber Yes
Quantity per packing format 48 pc
Response time max. [ms] 1 ms
Specification key MEP 2250-23-3-010-C10-C3BD08
Supply voltage [V] DC [Max] 30 V
Supply voltage [V] DC [Min] 8 V
Type MEP 2250
