140H-1 Heavy Duty Connector Link for Precision Roller Chain
Premium ANSI standard heavy-duty connector link (also called a master link) for 140H-1 precision roller chain. Essential for joining chain ends and enabling quick assembly and disassembly in high-load agricultural equipment, conveyors, and industrial machinery requiring maximum strength.
Key Features:
- ANSI standard compliant – works with all standard 140H heavy-duty roller chain
- Heavy-duty design for increased load capacity over standard 140 chain
- Available with cotter pin or riveted attachment
- Heat-treated components for maximum strength and durability
- Precision manufactured for proper fit and smooth operation
- Enables quick chain assembly and disassembly
- Sold individually
ANSI Specifications:
- Chain Size: 140H-1 Heavy Duty
- Pitch (P): 1.750″
- Roller Width (W): 1.000″
- Pin Diameter: 0.500″
- Plate Thickness: Heavier than standard 140 for increased strength
What is a Connector Link?
A connector link (also called a master link or connecting link) is a special removable link used to join the two ends of a roller chain loop. Unlike standard chain links that are permanently assembled, connector links feature a removable side plate secured with either a cotter pin or rivet. This design allows you to connect and disconnect chain without special tools, making installation, maintenance, and repairs much easier.
Attachment Options:
- Cotter Pin (Recommended): Secure attachment for high-load applications, pins must be properly spread after installation
- Riveted: Permanent installation for maximum strength, use when connector link will not need removal
Installation Notes:
- Connector links are slightly weaker than standard links – position away from high-stress areas when possible
- For cotter pin style, ensure pins are properly spread after installation
- Inspect cotter pins regularly and replace if damaged or loose
- Consider using offset link if odd number of chain links is required
Common Applications:
- Heavy-duty agricultural equipment and machinery
- High-load conveyors and material handling systems
- Industrial drives requiring increased strength over standard chain
- Any application requiring periodic chain removal for maintenance
Expert Help from the Midwest
Based in the heart of American agriculture, we bring over 17 years of hands-on experience specializing in agricultural chain systems. Need help selecting the right connector link attachment style or have questions about installation? Call us at or . We’re here to help you find the right solution.
Matching offset links and roller chain also available.
