5.118"(130mm) x 50.5"(1282.7mm) x 3.543"(90mm) Double Acting Hydraulic Cylinder

5.118″(130mm) x 50.5″(1282.7mm) x 3.543″(90mm) Double Acting Hydraulic Cylinder

Original price was: $499.95.Current price is: $99.99.

SKU: 904014 Category:

Description

5.118″ (130mm) x 50.5″(1282.7mm) x 3.543″ (90mm) DOUBLE ACTING HYDRAULIC CYLINDER
New, welded cylinder with bolt-on gland cap.

SPECIFICATIONS
  • Double Acting
  • Bore x Stroke 130mm (5.118″) x 50.5″(1282.7mm)
  • Barrel Thickness 1/2″
  • Pressure 3000 PSI max.
  • Rod Dia. 90mm (3.543″)
  • Ports 3/4″ Four-Bolt Flange, Code 61
  • Retracted Length 73-3/4″
  • Shpg. 510 lbs.
END MOUNTINGS
  • Rod End Tang
  • Max Thickness 3-3/4″
  • Pin Center to Tang End 2-13/16″
  • Pin Hole 80mm (3.149″)
  • Base End Tang
  • Max Thickness 3-3/4″
  • Pin Center to Tang End 2-3/4″
  • Pin Hole 80mm (3.149″)
