Description
Specifications
- Made by Eurocardan
- Extended length: 76″
- Collapsed length: 51.6″
- 35 HP at 540 RPM
- 54 HP at 1000 RPM
- AX 4 series 1110 mm or 44″ closed up from center of the universal joint to the center of the universal joint
- As 1/3/8″ x 6 spline on one end and 1″ round with a 1/4″ keyway & 1/4″ set screw on the implement end
- Often used with sprayer pumps with 1″ shafts
| Assembly Description | Series Size | Length Overall | Description I.E. = Implement End – T.E. = Tractor End |
|---|---|---|---|
| AX41110F-SMKEY | 4 | 51.6″ | 1″ smooth bore / keyway / set screws / 1 3/8-6 T.E. |
