Description
Specifications
- Made by Eurocardan
- Extended length: 76″
- Collapsed length: 51.6″
- 35 HP at 540 RPM
- 54 HP at 1000 RPM
- AX series 4 – 1110/44″ length from the center of the universal joint to the other universal joint closed up
- Tractor end is 1-3/8″ x 21 spline & the equipment end is a 1 ” round w/ 1/4″ keyway & 1/4″ set screw
Smooth Bore & Shear Pin Implement End Yoke
| Assembly Description | Series Size | Length Overall | Description I.E. = Implement EndT.E. = Tractor End |
|---|---|---|---|
| AX41110F-SMKEY-1021 | 4 | 51.6″ | 1″ smooth bore / keyway /set screws / 1 3/8-21 T.E. |
