Description
AMT 3S9XZR 3 Inch Trash Pump, 8 HP, Hatz 1B40 Diesel Motor
IPT Portable High Volume, Self-priming Centrifugal Trash pumps include easy cleanout with replaceable cast iron impeller and volute that resist abrasion/wear. All pumps feature aluminum housing, cast iron wearparts, built-in check valve, suction strainer and heavy duty steel roll frame. Heavy duty cast iron flanges with male NPT threads that rotates in 90° increments. Easy access fill plug on discharge port.
Features:
- Cast Aluminum with Internal Cast Iron Wearparts for Durability
- Silicon Carbide/Viton® Mechanical Seal
- EPDM/EPR O-Rings Standard with Optional Viton®
- 3˝ or 4˝ Removable Male NPT Suction and Discharge Ports
- Discharge Rotates in 90° Increments
- Engine Options: Honda, LCT Storm Force Gasoline or Hatz Diesel Engines
- Maximum Solids Handling up to 2˝
- Maximum Flow up to 530 GPM
- Maximum Head up to 112 Ft.
- Self-Priming to 26 Ft.
- Wheel Kit Optional
Specifications:
- Motor: Hatz 1B40 Diesel
- Motor HP: 8 HP
- Pump Body: Cast Aluminum
- Suction/Discharge: 3″ NPT
- Seal Material: Viton
- Max Flow Rate: 390 GPM
- Max Working Pressure: 78 PSI
- Max Temperature: 160° F
- Tank Size: 1.32 Gallons / 5 Liters
- Run Time: 2.7 Hours
Resources:
Pump Datasheet
Owners Manual
