Description
Features military-grade aluminum frame members with heavy-duty bearings for superb cutting with unsurpassed accuracy, smoothness, and durability. Wide, sliding fences support crown molding for up to 7-1/2″ vertically nested and 6-1/2″ of base molding. SHADOWLINE™ LED cut alignment system displays a precise cut line with no demand for readjustment. Provides 60° right and 50° left angles with 10 miter detents positive stops at the most common miter positions. Patented load arm support bracket is military-grade aluminum that delivers incredible accuracy for many years.
- 12″ blade with versatile flip-down fence design for 18″ crosscut capacity
- Adjustable crown fence lock increases stacked crown capacity at 45° to 7-1/2″
- Dual bevel 47° left/47° right with front bevel release and 7 positive stops at the most popular bevel angles
- Easy-to-reach lever override to move between stops
- Flip-down slide lock for super accurate plunge cuts
- Easily adjustable sliding tension
- Molded handle and ergonomic trigger
- 15 amp motor
- Blade brake
- Adjustable cutting depth
- Clear retractable blade guard
- 1-1/2″ dust port
Motor: 15 amp, 120V
Speed: 4,000 RPM
Blade Size: 12″
Arbor: 1″
Max. Cut Thickness: 6.5″
Cord Length: 7′
Max. Miter Cut Left: 50°
Max. Miter Cut Right: 60°
Maximum: 1.5″ x 17.25″ (2 x 18 lumber)
Miter 0° / Bevel 0°: 3.5″ x 13.25″ (4 x 14 lumber)
Miter 0° / Bevel 45°: 1.5″ x 13.25″ (2 x 14 lumber)
Miter 45° / Bevel 0°: 3.5″ x 9.25″ (4 x 10 lumber)
Miter 45° / Bevel 45°: 1.5″ x 9.25″ (2 x 10 lumber)
Baseboard (Vertical): 6.5″
Crown (Nested): 7.5″
Overall size: 30″ x 21.5″ x 25.5″
Weight: 57 lbs.
Includes
work clamp
dust bag
2 support extensions
2 extension clamps
2-1/2″ dust port
