Description
Features:– 4 to 20 mA or digital (S3L) output
– Standard 3/4″ NPT process connection
– One piece injection molded PVDF body
– PT1000 platinum RTD in extended tip for quick response
– Easy Installation
– Threaded for in-line or submersible installation
Applications:
– Plating bath temperature control
– Heat exchange monitor
– RO and DI system monitor
– Hot/cold mixing system monitor
– Data Acquisition
– Cooling loops
– Effluent monitoring
– HVAC
– Chemical procession
Specifications
– Output: Digital (S3L) output or 4 to 20 mA
– Accuracy: +/- 0.9°F
– Response Time: 10 secs
– Sensing End Connection: 3/4″ NPT Male Thread
– Cable-End Connection: 3/4″ NPT Male Thread
– Operating Temperature: 14°F to 232°F
– Enclosure: NEMA 4X/IP65
– Shipping Weight: 0.5 lbs
– Standards and Approvals: CE, FCC, UL, CUL
RoHS Compliant, China RoHS
Manufactured Under ISO 9001 for quality and ISO 14001 for Environmental Management and OHSAS 18001 for occupational health and saftey
