Description
Features:
-
Measurement range: 0.1 to 20 ppm (mg/l) free chlorine
-
Integrated Pt1000 temperature element for automatic temperature compensation
-
Embedded memory chip stores sensor information including calibration and service data
-
DryLoc® quick-connect with gold-plated contacts ensures a watertight and reliable seal
-
Accurate and repeatable measurements when paired with GF 2650 Electronics
-
CPVC body with gold working electrode and silver halide reference
Applications:
-
Water distribution networks
-
Ground and surface water monitoring
-
Food and beverage process water
-
Swimming pools and water parks
-
HVAC cooling water systems
Specifications:
| Parameter | Specification |
|---|---|
| Measurement Range | 0.1 to 20 ppm (mg/l) |
| Repeatability | ±0.08 ppm or 3% of range (whichever less) |
| Response Time (T90) | <2 minutes |
| Operating pH Range | 5.5 to 8.2 pH |
| Temperature Range | 5°C to 45°C (41°F to 113°F) |
| Pressure Rating | Max 7 psi @ 25°C (0.48 bar @ 77°F) |
| Required Flow Rate | 8–12 GPH (30.24–45.36 LPH) across membrane |
| Connection | DryLoc® connector |
| Materials (Wetted Parts) | PVC, PTFE, FKM, Nylon, Silicone |
| Shipping Weight | 0.30 lb (0.14 kg) |
| Certifications | UKCA, CE, FCC, RoHS, ISO 9001 |
Compatible Components (Sold Separately):
-
2650 Amperometric Electronics
-
9950-3 or 9950-4 Chlorine Controller
-
Flow Cell 3-3610-1 / 3-3610-2
-
Sensor Maintenance Kit: 3-2630.398
-
Membrane Replacement: 3-2630.394
-
Electrolyte Kit: 3-2630.391
