Description
HILO Jacketed Motor Lead for Franklin 4 Inch Pump Motors – 12 Gauge, 2 Wire
Available in lengths up to 150 ft. Hi-Lo supreme jacketed type, UL approved cable furnished in pre-cut lengths with water tight Viton plug on one end for direct connection to a Franklin 4” motor. Cable uses stranded copper conductors.
Specifications:
- CONSTRUCTION: Jam nut/sleeve – 316 stainless steel, bushing – 4” Viton, sleeve 316 stainless steel
- CONDUCTORS: 12 AWG 19/25 TPC
- INSULATION: STPE .045” wall nom.
- COLOR CODE: Black, Red, Green
- OVERALL DIAMETER: 0.405”
Datasheet
