Description
FEATURES
– High Flow TFC low pressure membranes
– High Quality Gloss 300 PSI FRP Housings – SS housings available at no additional cost
– Easily Replaceable Motor Mounting System – For easy field repairs
– Schedule 80 PVC Fittings – For easy field repair
– Brass Inlet Shut-off Valve
– Low Pressure Mechanical Switch
– Permeate & Concentrate Flow Meters
– Concentrate Pressure Gauge – Liquid filled for accurate and steady pressure readings
– Stainless Steel High Pressure Centrifugal Pump – For long lasting performance
– High Flow 5 Micron Pre-filter – Front mounted for ease of access
– Electrical Connection – 220VAC required
– RO Controller – Simple RO controller used for maximum reliability
SPECIFICATIONS
– Production GPD: 1600 (Based off of max 2,000 mg,L at 225 psi, 15% recovery, 77°F, pH 6.5-7.0)
– Membrane: (1) 4″ x 40″
– Permeate GPM: 1.11 GPM
– Feed GPM: 6.0 GPM (minimum pressure of 20 psi)
– % Recovery: 19-23%
– Pump: 0.75 HP
– Electrical: 220 VAC/ 60 Hz, 9.6 Amp
– Circuit Size: 15 Amp
– Inlet: 3/4″
– Permeate: 1/2″
– Concentrate: 1/2″
– Floor Model Unit Dims (DxWxH): 22″ x 17″ x 55″
