Description
FEATURES
– Carbon Steel Frame for strength & rigidity– Powder Coated Frame for long life & durability– Extended Frame Legs with plastic end caps for protection from ground contact and ease of movement– Replaceable Motor Mounting System – makes field repairs easy, bracket mounts to motor and slides over frame– True Union Couplings on the inlet & outlet of motor – Stainless Braided Hoses for protection against corrosion, leaks & fraying– Replaceable Schedule 80 PVC fittings for ease of field repairs– Quick Connect Fittings on gauges & recycle operating for ease of service– Brass or Stainless Steel inlet shut-off valve– High flow TFC Low Pressure Membranes – additional element types & ratings available– High Quality Gloss 300 PSI FRP Housings – SS housings available at no additional cost– Integrated Recycle Valve– Low Pressure Mechanical Switch with time delay snubber valve– Permeate & Concentrate Flow Meters– Liquid Filled Gauges for accurate & steady pressure readings– Panel Mounted Concentrate Pressure Gauge– Stainless Steel High Pressure Centrifugal Pump for lasting performance– Pump Throttle Valve & Pipe-mounted Discharge Pressure Gauge– Float Switch & Pretreatment Interlocks – standard on all systems– High Flow 5 Micron Front-mounted Pre-filter for ease of service– Electrical Connection – 220VAC connection required FREE UPGRADE to NRO Controller – Digital display electronic control box with permeate TDS display, low pressure auto reset and level control options
SPECIFICATIONS
– Production GPD: 1600 (Based off of max 2,000 mg,L at 225 psi, 15% recovery, 77°F, pH 6.5-7.0)
– Membrane: (1) 4″ x 40″
– Permeate GPM: 1.1 GPM
– Feed GPM: 6.0 GPM (minimum pressure of 20 psi)
– % Recovery: 19-30%
– Pump: 1 HP
– Electrical: 220 VAC/ 60 Hz, 9.6 Amp
– Circuit Size: 15 Amp
– Inlet: 3/4″
– Permeate: 1/2″
– Concentrate: 1/2″
– Floor Model Unit Dims (DxWxH): 34″ x 34.5″ x 58.5″
