Description
2″ flanged cast iron butterfly valve with gear-operated handle. This valve features an EPDM encapsulated ductile iron disc and stainless steel stem with metal bushings. Not recommended for steam service.
Features
- Valve pressure rating 200 psi
- Max temperature rating 200°F
- Flanged style
- EPDM encapsulated ductile iron disc
- Stainless steel stem with metal bushings
- Operating mechanism: Bare stem, infinite position plate and lock, lever lock, manual gear operator
- Not recommended for steam service
- Designed to meet MSS SP-67
- MSS SP-25 (markings)
- Certified to NSF/ANSI/CAN 372-2020, Drinking Water System Components – Health Effects
