Description
PRECISION OIL TIGHT ROLLER LEVER LIMIT SWITCH
Brand new, RELAY & CONTROLS CORP limit switch. Gasket on housing for dust proof, oil tight and water resistant sealing. Operating temperature range 5°F-175°F. Maximum operating frequency 30 operations per minute.
SPECIFICATIONS
- Model RCL-300
- Contact Type 1 Normally Open, 1 Normally Closed
- Contact Ratings:
10 Amps @ 125 VAC
1/2 HP @ 125 VAC, 1 HP @ 250 VAC
300VAC max. - Actuator details2-1/8″ arm w/3/4″ dia. roller
- Operating Force Max. 3 in.lbs.
- Release Force Min. 1/2 lb.
- Pre-Travel Max.15°-20°
- Over-Travel Min.25°
- Differential Travel Max.12°
- Travel Force Max. 4 in.lbs.
- Total Travel Min. 43°
- TerminalsScrew
- Size1-5/8″ x 1-1/2″ x 4″ (housing only)
- Mount 4 holes 1-1/8″ x 2-3/8″
- Shpg.1 lbs.
