Description
Schneider LA1KN40 4NO Auxiliary Contact Block, TeSys K, Screw Clamp Terminals
TeSys K instantaneous auxiliary contact block, for contactors LC.K, LP.K, CA.K with screw clamp terminals (except LP4K, LP5K, CA4K). It provides 4NO contacts rated up to 10A 690V AC, connection by screw clamp terminals. Front mounting by clip-on, it procures high reliability and durability. Multi standards certified (IEC, UL, CSA, CCC).
Specifications
| MPN | LA1KN40 |
| Range | TeSys |
| Product Name | TeSys K |
| Product/Component Type | Auxiliary contact block |
| Range Compatibility | TeSys K LC1K TeSys K CA2K TeSys K CA3K |
| Mounting Location | Front |
| Pole Contact Composition | 4 NO |
| Contacts Operation | Instantaneous |
| [Ue] Rated Operational Voltage | 690 V AC 25…400 Hz |
| [Ui] Rated Insulation Voltage | 690 V IEC 60947-5-1 600 V UL 60947-5-1 600 V CSA C22.2 No 60947-5-1 |
| [Ith] Conventional Free Air Thermal Current | 10 A (at 122 °F (50 °C)) |
Standards
- EN/IEC 60947-5-1
- UL 60947-5-1
- CSA C22.2 No 60947-5-1
- GB/T 14048.5
- JIS C8201-5-1
- UL 60335-2-40:Annex JJ
Certifications
- CB Scheme
- CCC
- UL
- CSA
- CE
- UKCA
